Stratasys J8 Series

Bring your Boldest Ideas to Life

Give every idea the maximum chance of success by creating realistic prototypes that faithfully reflect your design.

From ideation to creation, the multi-material J850, J835, and J826 under the J8 Series deliver a fully-functioning, PANTONE™ validated prototype 200% faster than traditional methods with unrivaled aesthetics for designers.

With the capability to model multiple prototypes in one print – it has never been easier to get prototypes to all stakeholders and improve overall design communication.

Description

Designed for Designers

Design and creativity have no limits. You can now perfect prototypes without limits. Create, refine, and design the best product possible with tried and trusted technology that simplifies the entire design process.

Create better quality prototypes with higher accuracy, more materials, and superior finishes than traditional methods – with savings of up to 70%.

See yourself in the J8 Series. Designed for –  Product Designers, Packaging Designers, Design Engineers, Biomedical Engineers.

Stratasys J750 and J735 are the first 3D printing offerings fully endorsed by Pantone.Pantone™ Color Validated

Create realistic prototypes that faithfully replicate your design for maximum success with your design ideas. Exactly as you imagined. All the time.

Besides supporting over 500,000 color options, the J8 Series is also one of the world’s first 3D printing system to come with PANTONE color validation and multi-material capabilities for unrivaled aesthetic results.

By modeling multiple prototypes in one print – it has never been easier to get prototypes to all involved stakeholders and improve design communication.

Explore Applications

Brilliant designs should not have limits.

The Stratasys J8 Series helps solve design challenges in a more creative, nimble and cost-effective way.

From early-stage prototypes to high fidelity models, the J8 Series is designed for all stages of design and a multitude of applications.

Explore application examples and imagine what the J8 Series could do in your designer’s hands.

Download the Ebook to get a closer look at the Stratasys J8 Series of 3D printers and get a better understanding on how they make an impact on design realism across all industries and disciplines.

Download Ebook

Prototype With Stratasys J8 Series 3D Printers

Brilliant designs shouldn’t have limitations. Realize and elevate your ideas more quickly and precisely with Stratasys J850, J835 and J826 3D printers — designed for all who design.

More power to design with more materials

Load up to seven materials at one time with the printer’s multi-material capacity. Expansive color and texture combinations help you to create the most realistic models in the shortest time possible.

Business Impact in a nutshell


Request A Quote Now

Specifications

So what’s the difference between J850, J835, and J826?

Each of these 3D printers comes with the same technology and material capability.

However, the J850 and J835 differ in different build tray sizes to meet your specific budgetary and design needs. The J826 is the little brother of the J8 series with the smallest build tray but also comes at the lowest cost.

*VeroUltraClear will come to the J826 in Q2 2020.


Stratasys J8 Series
MAXIMUM BUILD SIZE
J850: 490 x 390 x 200 mm (19.3 x 15.35 x 7.9 in.)
J835: 350 x 350 x 200 mm (13.8 x 13.8 x 7.9 in.)
J826: 255 x 252 x 200 mm (10 x 9.9 x 7.9 in.)
MODEL MATERIALS
Vero™ family of opaque materials including
neutral shades & vibrant VeroVivid™ colors
Agilus30™ flexible material
Transparent VeroClear™ and VeroUltraClear™
DIGITAL MATERIAL OPTIONS
Over 500,000 colours
Digital ABS and Digital ABS2 in ivory and green
Rubber-like materials in a variety of Shore A values
Translucent color tints
LAYER THICKNESS
Horizontal build layers as fine as 14 microns (High Quality Mode)
and 55 microns (Super High Speed Mode)
MACHINE DIMENSIONS
J835/J850: 140 x 126 x 110 cm (55.1 x 49.6 x 43.3 in)
J826: 82 x 131 x 66.5 cm (32.28 x 51.57 x 26.18 in)
Machine Cabinet: 111.9 x 65.6 x 63.7 cm (44 x 25.8 x 25.1 in)
MACHINE WEIGHT
J835/J850: 430 kg (948 lbs)
J826: 234 kg (516 lbs)
Machine Cabinet: 153 kg (337 lbs)
BUILD MODES
High Quality: up to 7 base resins, 14 micron (0.00055 in.) resolution
High Mix: up to 7 base resins, 27 micron (0.001 in.) resolution
High Speed: up to 3 base resins, 27 micron (0.001in.) resolution
Super High Speed: 1 base resin, 55 micron (0.002 in.) resolution

* Super High Speed is not available for J826
ACCURACY
For J835/J850: Typical deviation from STL dimensions, for models printed with rigid materials, based on size: under 100 mm – ±100μ; above 100 mm – ±200μ or ± 0.06% of part length, whichever is greater.

For J826: Typical deviation from STL dimensions, for models printed with rigid materials, based on size: under 100 mm – ±100μ; above 100 mm – ±200μ.
BUILD RESOLUTION
X-axis: 600 dpi; Y-axis: 600 dpi; Z-axis: 1800 dpi
WORKSTATION COMPATIBILITY
Windows 10
NETWORK CONNECTIVITY
LAN – TCP/IP
POWER REQUIREMENTS
100–120 VAC, 50–60 Hz, 13.5A , 1 phase
220–240 VAC, 50–60 Hz, 7A , 1 phase
SUPPORT MATERIALS
SUP705 (water jet removable)
SUP706B (soluble)
REGULATORY COMPLIANCE
CE, FCC, EAC
SOFTWARE
GrabCAD Print
SPECIAL FACILITY REQUIREMENTS
 18 - 25°C;
Relative humidity 30-70 % (non-condensing)

Software

GrabCAD Print Software

GrabCAD Print software makes 3D printing easy, accessible and connected. Read and understand CAD files natively to help you simplify the preparation, scheduling, monitoring, and reporting of all your print jobs. GrabCAD Print offers an efficient workflow that streamlines job management in shared office and model shop environments using Stratasys 3D Printers.



Print directly from CAD
Save time by directly printing CAD files, without converting and fixing STL files. You can also print directly from within Creo 4.0 or the SOLIDWORKS® Add-in.

Pantone Validated
With nearly 2,000 available options, match PANTONE colors in a single click, with no time-consuming painting or trial-and-error matching.

Get Started Fast
Smart default settings, tooltips, and notification help you to print seamlessly, without the need to fiddle with the settings.

See what you’re doing
Make necessary adjustments when required, with a detailed view of your model, tray, and slice preview.


Request A Quote Now

PANTONE™ Validated

Print in Pantone

When design decisions are color critical, the J8 Series printers provide PANTONE validation and make the PANTONE Matching System (PMS) colors available in 3D printed form. Color matching to PANTONE colors is possible in a single click from the GrabCAD Print software. By providing a quicker, more realistic expression of color in models and prototypes, organizations save hours over traditional paint matching or iterative color-matching processes.


Request A Quote Now

Resources

Learn how Stratasys SUP706B soluble support material dissolves easily, giving you the freedom to print complex and delicate features, without the hassle of laborious post-processing.
