Stratasys J5 DentaJet

Load one tray
and walk away

The newest addition to the Stratasys Dental Series, J5 DentaJet lets you create more models in a single print with its large capacity, 360° print tray for high volume production.

Reduce costs by printing with mixed materials in a single tray, and you can even operate it unattended.

Enjoy printing the most realistic full-color models with the precision and realism expected of Stratasys PolyJet systems, without sacrificing patient-specific accuracy.

Description

Quality Made Compact

  • Small footprint makes it easy to fit in small-to-medium labs but yet has a large print tray to create parts.
  • Reduce manual labor with unattended operation, fewer changeovers, less loading time, and minimal post-processing while maximizing output.
  • Being able to use different materials in a single print job, J5 DentaJet makes it feel like owning 3 printers in one.
  • Print an implant case with a rigid opaque model together with a soft gingiva mask and a biocompatible transparent surgical guide, or print a removable partial denture in a castable material together with the patient model.

Harness the
power of color

Leverage on the full-color capability to improve workflow and tracking and communicate more information.

As the only dental printer that is able to create highly realistic replicas of the patient’s mouth, the J5 DentaJet lets you reduce C&B remakes to enable better clinical outcomes and communication between the lab, clinic, and patient.

Big Impact
with Simplified Workflow

  • The Separator Digital Material enables orthodontic devices to be separated easily from the printed model and results in better surface quality and decreased manual labor.
  • Streamline your workflow with GrabCAD Print integration that’s easy to use and requires minimal training to get up to speed. Create unique and highly realistic models to save time and reduce errors.
  • Enable better clinical outcomes and facilitate better communication between the lab, clinic, and the patient with realistic, patient-specific models.

Business Impact

Transforming Dentistry

For labs that realize the true value of 3D printing, the time to act is now, not the future. By fully embracing digital dentistry, labs can grow their businesses, produce exceptional quality models, and shorten turnaround time – without adding staff or time.

The multi-material 3D printing capability of Stratasys Dental solutions truly broadens your versatility in printing a wide range of cases from implant models with soft tissues, custom-fit surgical guides, aligner setups, indirect bonding trays, restoration mock-ups, and more with precision.

Discover the Stratasys Difference!

Dental Applications for every need

IMPLANTOLOGY

Maximize production and simplify the complexity of implantology.

Applications:

  • Implant models
  • Surgical guides
  • Gingiva masks

Print all on one tray. With only two trays, print as many as 41 implant cases* daily.

* one case equals a full arch model, opposite side, surgical guide, and gingiva mask.

ORTHODONTICS

Cut days off delivery times and produce more orthodontic appliances.

Applications:

  • Models
  • Indirect bonding trays

Simplify the production of acrylic orthodontic devices with Separator Digital Material which coats models making.

REMOVABLES

Reduce manual labor and increase production.

Applications:

  • Models
  • RPD frameworks
  • Custom impression trays
  • Try-ins

Print all on one tray and up to 26 cases** per day with only two trays.

** One case equals RPD framework and model.

CROWN AND BRIDGE

Produce large volumes of models in high-resolution materials.

Applications:

  • Models — quadrant, full upper and lower with removable dies.

Eliminate delays and inaccuracies of manual labor.

Materials for J5 DentaJet

Leverage full-color capability and realism to differentiate your dental lab. The J5 DentaJet offers over 500,000 colors and three biocompatible materials to cater to different applications.

In addition, the Separator Digital Material makes acrylic orthodontic devices, such as Hawley Retainers, separate easily from the printed model and results in better surface quality and decreased manual labor.

Biocompatible MED610

Transparent, biocompatible PolyJet material medically approved for bodily contact.

Biocompatible MED620

Opaque white material with A2 shading designed to provide the best color match in the industry.

Biocompatible MED625FLX

Flexible, transparent material for printing indirect bonding trays and soft gingival masks.

Vero

Provides unique full-color capabilities to produce smooth, accurate and realistic models.

Specifications

Stratasys J5 DentaJet
MODEL MATERIALS
Biocompatible materials:
  • Biocompatible Clear MED610
  • VeroGlaze
  • Flexible clear biocompatible material MED625FLX

    Vibrant colors including:
  • VeroCyanV (RGD845)
  • VeroMagentaV (RGD852)
  • VeroYellowV (RGD838)
  • VeroDent PureWhite (DEN847)
  • DIGITAL MODEL MATERIALS
    Unlimited number of composite materials including:
  • Over 500,000 colors
  • Separator Digital Material
  • SUPPORT MATERIALS
    SUP711 (WaterJet removable)
    BUILD AREA
    140 x 200 x 190 mm
    BUILD MODES
    High Quality Speed (HQS) - 18.75 μm
    LAYER THICKNESS
    Horizontal build layers down to 18 microns (.0007 in.)
    NETWORK CONNECTIVITY
    LAN-TCP/IP
    SYSTEM SIZE
    651 x 661 x 1511 mm
    SYSTEM WEIGHT
    228 kg
    OPERATING CONDITIONS
    Temperature 18 – 25˚C (64 – 77˚F);
    relative humidity 30-70% (non-condensing)
    POWER REQUIREMENTS
    100 - 120 VAC, 50 - 60Hz, 10A, 1 phase
    REGULATORY COMPLIANCE
    CE, FCC, EAC
    SOFTWARE
    GrabCAD Print

    Request A Quote Now

    Comparison

    If you’re looking for a smaller footprint, high-efficiency, all-in-one dental parts printer, the J5 DentaJet is it. If you’re looking for a more tailored solution for your dental applications we have other options that may be a better fit.

    Here are the specs below to help you decide.

    Download Comparison

    J5 DentaJet
    Objet 30 Dental Prime
    J720 Dental
    J700 Dental
    All cases on 1-tray, high-efficiency printer with a
    smaller footprint for all dental labs.
    Desktop, entry-level printer for precise digital dentistry at an affordable price.All-cases-on-1-tray, high production printer for large full-service and orthodontic labs.A high-throughput, clear aligner manufacturing
    solution.
    APPLICATIONS
    Dental tooling (high-volume):
  • Models: C&B, implant, orthodontic, removable, maxillofacial, color
  • Surgical guides
  • RPD frameworks
  • Try-ins
  • Gingiva masks
  • Indirect bonding (IDB) trays
  • Custom impression trays
  • Dental tooling (low volume):
  • Models: C&B, implant, orthodontic, removable
  • Surgical guides
  • RPD frameworks
  • Custom impression trays
  • Try-ins
  • Dental tooling (maximum
    volume):
  • Models: C&B, implant, orthodontic, removable,
    maxillofacial, full-color/highest level of realism
  • Surgical guides
  • Gingiva masks
  • Indirect bonding (IDB) trays
  • RPD frameworks
  • Custom impression trays
  • Try-ins
  • Orthodontics:
  • Mass producer of clear aligner models
  • MODEL MATERIALS
  • Biocompatible rigid transparent (MED610)
  • Biocompatible rigid A2 color (MED620)
  • Biocompatible flexible transparent (MED625FLX)

  • VeroDent PureWhite

  • Vibrant colors including:
    - VeroCyanV
    - VeroMagentaV
    - VeroYellowV
  • Biocompatible rigid
    transparent (MED610)
  • Biocompatible rigid A2
    color (MED620)
  • VeroDentPlus (MED690)
  • Biocompatible rigid transparent (MED610)
  • Biocompatible rigid A2 color (MED620)
  • Biocompatible flexible transparent (MED625FLX)

  • VeroDent PureWhite

  • Vibrant colors including:
    - VeroCyanV
    - VeroMagentaV
    - VeroYellowV

  • VeroDent (MED670)
  • VeroDentPlus (MED690)

  • Vero family of opaque colors including neutral shades (CYMK)

  • Tango and Agilus30 families of flexible materials
    • Transparent VeroClear
    • VeroUltraClear
  • VeroDent (MED670)
  • VeroDentPlus
    (MED690)
  • MAX MATERIALS
    5161
    SUPPORT MATERIALS
    SUP711 (WaterJet removable)SUP705 (WaterJet removable)
    SUP706B (Soluble)
    SUP705 (WaterJet removable)
    SUP706B (Soluble)
    SUP705 (WaterJet removable)
    SOFTWARE
    GrabCAD PrintObjet Studio intuitive 3D printing softwareGrabCAD PrintGrabCAD Print
    CARTRIDGE CAPACITY
    1.1kg1kg3.6kg3.6kg
    TRAY SIZE
    1,174cm²600cm²1,911cm²1,911cm²
    SYSTEM SIZE & WEIGHT
    651 x 661 x 1511mm; 228kg82.5 x 62 x 59cm; 106kg1,400 x 1,260 x 1,100mm; 430kg

    Material Cabinet: 670 x 1,170 x 640mm; 152kg
    1,400 x 1,260 x 1,100mm; 430kg

    Material Cabinet: 670 x 1,170 x 640mm; 152kg
    HIGHEST RESOLUTION
    18.75μm16μm14μm55μm
