stratasys f123 series 3d printer

STRATASYS F123 SERIES

Simple and Smart Prototyping
in the Office

The Stratasys F123 Series 3D Printers combine Stratasys’ patented FDM technology with a design-to-print GrabCAD software system to bring you the most versatile and intelligent solutions for prototyping workflows. Being easy to operate and maintain, it’s perfect for the office environment.

Categories: ,
Download Brochure Request a Quote Now

Description

F123 Series 3D Printer Overview

Outperform the market with 39% Lower Labor and Material Costs with TPU 92A.
An Elastomer that’s virtually indestructible with very high elongation

Finally, a TPU (thermoplastic polyurethane) material that makes the production of complex parts much easier, and relieves pain points commonly found in current Elastomer 3D printing options.

As the only elastomer with real soluble support, rapid prototyping has never been easier with a Stratasys 3D Printer.

TPU 92A allows for quick turnaround of parts in a matter of hours compared to conventional methods which take days. It is also able to support large build size and create complex geometrical designs reliably and is something that’s unachievable by competing technologies like SLS, FFF, and others.

F123 TPU Savings

6 Different Material Options

With the Stratasys F123 Series, you can print everything from fast, low-cost concepts to robust assemblies.

Choose from up to 6 different materials, including TPU 92A elastomer with easy-to-remove soluble support material*.

*Stratasys F170 and F270 support TPU 92A, PLA, ABS-M30, and ASA. Stratasys F370 supports the above as well as Diran 410MF07 and PC-ABS.

PLA uses breakaway support only. TPU 92A uses QSR (SR-35) soluble support. Diran 410MF07 uses SUP4000B support.

Available materials: TPU 92A, PLA, ABS-M30, ASA, PC-ABS, Diran 410MF07

F123 Material Change

Intuitive 3D Printing Software for Professionals

Print from any Devices
Cloud-connected ability allows you to directly print from any browser from your device of choice

Remote Scheduling and Monitoring
Gain access, monitor material levels for budget planning, and print from anywhere regardless of location as long as there’s an internet connection

Efficient Print Scheduling
Print scheduling is made more efficient with a constantly updated listing of machine availability, estimated job duration, and other key considerations.

Always Be Notified
Be it a print job completion or if an error has occurred, notifications allow you to act accordingly.

Learn More
GrabCAD Print Schedule Screen
Request A Quote

Specifications


F170
F270
F370
SYSTEM SIZE
1,626 x 864 x 711 mm
(64 x 34 x 28 in.)
BUILD TRAY DIMENSION
254 x 254 x 254 mm
(10 x 10 x 10 in.)
305 x 254 x 305 mm (12 x 10 x 12 in.)
355 x 254 x 355 mm (14 x 10 x 14 in.)
MODEL MATERIALS
TPU 92A, PLA, ABS-M30, ASA
TPU 92A, PLA, ABS-M30, ASA
TPU 92A, PLA, ABS-M30, ASA, PC-ABS
LAYER THICKNESS
PLA (0.010 in./0.2554 mm)
ACCURACY
Parts are produced within an accuracy of +/- .200 mm (.008 in),
or +/- .002 mm/mm (.002 in/in), whichever is greater.
MATERIAL DELIVERY OPTIONS
2 material spool bays
1 model, 1 for support.
4 material spool bays,
2 model, 2 for support.
NETWORK CONNECTIVITY
Wired: TCP/IP protocols at 100 Mbps minimum 100 base T, Ethernet protocol, RJ45 connector
Wireless: IEEE 802.11n, g, or b; Authentication: WPA2-PSK, 802.1x EAP; Encryption: CCMP, TKIP
SOFTWARE
GrabCAD Print
SYSTEM REQUIREMENTS
Windows 7, 8, 8.1 and 10 (64bit only)
with a minimum of 4GB RAM (8GB or more recommended)
OPERATING ENVIRONMENT
Operating: Temperature: 59-86oF (15-30oC), Humidity: 30-70%
RH Storage: Temperature: 32-95oF (0-35oC), Humidity: 20-90% RH
POWER REQUIREMENTS
100–132V/15A
or 200–240V/7A. 50/60 Hz
REGULATORY COMPLIANCE
CE, FCC, EAC, EMC (low-voltage directive),
TUV, FCC, RC, RCM, RoHs, WEEE, Reach

Software

GrabCAD Print Software

GrabCAD Print software makes 3D printing easy, accessible and connected. Read and understand CAD files natively to help you simplify the preparation, scheduling, monitoring, and reporting of all your print jobs. GrabCAD Print offers an efficient workflow that streamlines job management in shared office and model shop environments using Stratasys 3D Printers.



Print directly from CAD
Save time by directly printing CAD files, without converting and fixing STL files. You can also print directly from within Creo 4.0 or the SOLIDWORKS® Add-in.

Get Started Fast
Smart default settings, tooltips, and notification help you to print seamlessly, without the need to fiddle with the settings.

See what you’re doing
Make necessary adjustments when required, with a detailed view of your model, tray, and slice preview.



GrabCAD Print Schedule Screen


Organized print schedule
Management view of all printers allows you to optimize resources based on their availability, estimated job duration, and other key considerations.

Monitor material levels
Plan and budget by knowing how much material you have left for each printer.

Stay up to date
When you print is complete or if there is an error, there will be notifications to help you act accordingly.





Print from any device
Access GrabCAD Print directly as long there’s an internet connection, from any browser on your device of choice.

Schedule and monitor remotely
Gain access and print from any supported printer, even if it’s in a different geographic location.

Minimal training required
3D Printing is as easy as loading a part and clicking print, thanks to a straightforward interface.

Stratasys Insight Software

InSight



Print directly from your favorite CAD formats, eliminating the STL conversion and adjusting you used to do before printing. Optimize your productions with advanced control options that automatically adjust support structures and material extrusion paths, while giving you the ability to pause production in order to change materials or embed hardware or circuitry. Control Center lets you seamlessly share project information between users, creating a more streamlined, efficient workflow.

  • All Fortus systems include Insight and Control Center job processing and management software.
  • Compatible with GrabCAD Print for use with job reports, scheduling and remote monitoring.
