Stratasys Dental Series 3D Printers

Enhancing Digital Dentistry Applications

The Stratasys Dental 3D printing systems are driven by Stratasys’s PolyJet technology for increasing production capacities for various orthodontic appliances.

Description

Taking Digital Dentistry to Revolutionary Levels

Dental modelling can now be made convenient with the Stratasys Dental 3D Printers. Utilise the 3D Printing systems that we carry to speed up your dental workflow by using digitised CAD files to 3D Print your dental models.

With 4 types of Dental 3D printers to choose from, there is one that will best suit your dental practice and business needs.

KEY FEATURES



Objet30 OrthoDesk
Stratasys Objet30 Orthodesk 3D Printer3 MEDICALLY-APPROVED MATERIALS

VeroDentPlus: superior strength,
precision & durability.

Clear Bio-compatible
: for temporary
in-mouth placements.

VeroGlaze: for veneer try-in
& diagnostic wax-up.
AUTOMATED 3D PRINTING

The OrthoDesk 30 Printer reduces
fabrication time and increases output
per technician.
Objet 30 Dental Prime
Stratasys Objet30 Dental Prime 3D PrinterDETAIL LAYER THICKNESS UP
TO 16-MICRONS


Achieve finer detailing applications
of diagnostic wax-ups and
removable partial denture casting patterns.
3 PRINTING MODES


Experience versatility in the
Objet30 Dental Prime.
Choose between High Quality,
High Speed and Draft modes
to meet your specific 3D Printing needs.
Objet Eden260VS Dental Advantage
Stratasys Eden260VS Dental Advantage 3D Printer4 MEDICALLY-APPROVED MATERIALS

VeroDent: forhigh-quality detail, strength
and durability.

VeroDentPlus: for fine finishing and durability.

VeroGlaze: medically-approved for veneer
try-ins and diagnostic wax-ups.

Clear Bio-compatible: for orthodontic
appliances, delivery and positioning trays
as well as surgical guides for
temporary in-mouth placement.
16-MICRONS FINE LAYER RESOLUTION

Achieve precise detailing in
3D Printed stone models,
surgical guides, veneer or denture try-ins,
as well as delivery trays.
Objet 260 Dental
Objet260 Dental 3D Printer.INCREASED PRODUCTIVITY AND CAPACITY

Build diverse models on one tray and load multiple materials at once.

EASE OF USE

No digital design knowledge required to operate the printer.

ENVIRONMENTALLY SAFE DENTAL MATERIALS

Easy-to-handle cartridges which pose no biohazard safety concerns.

TRACEABILITY

Cartridges are individually sealed with specific lot numbers.
INCREASED THROUGHPUT AND EFFICIENCY

255 x 252 x 200 mm
Objet 260/500 Dental Selection
Stratasys Objet 260/500 Dental Selection 3D PrintersVERSATILE MATERIAL & COLOUR OPTIONS

Emulate gum-like softness and colours,
as well as subtle colour gradations in
natural tooth shades.

MANY MATERIALS IN ONE JOB

Create multi-material dental models in one piece.

EFFICIENT WORKFLOW

Maximise uptime by running your 3 frequently used materials concurrently.

INCREASED THROUGHPUT AND EFFICIENCY

Objet260: 255 x 252 x 200 mm
Objet500: 490 x 390 x 200 mm

Specifications


Objet30 OrthoDesk
Objet30 Dental Prime
Objet Eden260VS Dental Advantage
Objet 260/500 Dental Selections Systems
MODEL MATERIALS
VeroDentPlus (MED690) VeroGlaze (MED620)

Clear Bio-compatible (MED610)
VeroDentPlus (MED690) VeroGlaze (MED620)

Clear Bio-compatible (MED610)
 VeroDent (MED670) VeroDentPlus (MED690) VeroGlaze (MED620)

Clear Bio-compatible (MED610)
VeroDent (MED670) VeroDentPlus (MED690)
VeroGlaze (MED620)
Clear Bio-compatible (MED610)


VeroWhite VeroMagenta

TangoPlus TangoBlackPlus

Range of gum-like Digital Materials Digital Materials in a range of natural tooth shades
SUPPORT MATERIALS
SUP705 non-toxic gel-like photopolymer support
 SUP705 non-toxic gel-like photopolymer support
 SUP705 non-toxic gel-like photopolymer support


SUP707 (Soluble support Material)
SUP705 non-toxic gel-like photopolymer support
NET BUILD SIZE
300 x 200 x 100 mm (11.81 x 7.87 x 3.94 in)
300 x 200 x 100 mm (11.81 x 7.87 x 3.94 in)
260 x 260 x 200 mm (10.24 × 10.24 × 7.9 in)
Objet260: 255 x 252 x 200 mm (10.0 x 9.9 x 7.9 in)


Objet500: 490 x 390 x 200 mm (19.3 x 15.4 x 7.9 in)
LAYER THICKNESS
Horizontal build layers as ne as 30 microns (0.0011 in)
Horizontal build layers as fine as 16 microns (0.0006 in)
Horizontal build layers as fine as 16 microns (0.0006 in)
Horizontal build layers as fine as 16 microns (0.0006 in)
SYSTEM SIZE & WEIGHT
82.5 x 62 x 59 cm (32.28 x 24.4 x 23.22 in.); 93 kg (205 lbs)
82.5 x 62 x 59 cm (32.28 x 24.4 x 23.22 in.); 106 kg (234 lbs)
870 x 735 x 1200 mm (34.25 x 28.9 x 47.25 in); 410 kg (902 lbs.)
Objet260: 870 x 735 x 1200 mm (34.3 x 28.9 x 47.2 in); 264 kg (582 lbs.)


Material Cabinet: 330 x 1170 x 640 mm (13 x 46.1 x 26.2 in.); 76 kg (168 lbs.)

Objet500: 1400 x 1260 x 1100 mm (55.1 x 49.6 x 43.3 in.); 430 kg (948 lbs.)
Material Cabinet: 330 x 1170 x 640 mm (13 x 46.1 x 26.2 in.); 76 kg (168 lbs.)
WORKSTATION COMPATIBILITY
Windows 7/Windows 8
Windows 7/Windows 8
Windows 7 32/64-bit
Windows 7/Windows 8
NETWORK CONNECTIVITY
Ethernet – TCP/IP 10/100 base T
Ethernet – TCP/IP 10/100 base T
LAN – TCP/IP
LAN – TCP/IP
POWER REQUIREMENTS
single phase 100-120V~; 50-60Hz; 7A, 200-240V~; 50-60Hz; 3.5A
single phase 100-120V~; 50-60Hz; 7A, 200-240V~; 50-60Hz; 3.5A
110-240 VAC 50/60 Hz; 1.5 KW single phase
110-240 VAC 50/60 Hz; 1.5 KW single phase
REGULATORY COMPLIANCE
CE, FCC, RoHS

CE, FCC, RoHS
CE, FCC
CE, FCC
OPERATING ENVIRONMENT
Temperature 18-25°C (64-77°F); relative humidity 30-70%
Temperatu
Temperature 18-25°C (64-77°F); relative humidity 30-70%
Temperature 18-25°C (64-77°F); relative humidity 30-70%
Temperature 18-25°C (64-77°F); relative humidity 30-70%

Software

Objet Studio Software

Generate high-quality and accurate 3D models with great efficiency. Objet Studio automatically converts STL and SLC files from any 3D CAD application into build material and support 3D modeling slices.

In the software, you can also edit trays faster, perform routine system maintenance, assign materials and handle job queues using click-and-build wizards.

KEY FEATURES

User-friendly buildtray
that incorporates multiple
materials &
3D printed models.

Quick slicing so that 3D printing
can start prompty.



Multi-user Networking.



Support Removal

Prototypes created by the Stratasys Objet Dental Series 3D Printers use SUP705 and SUP707 support materials to create complex geometrics and structures.

SUP 705 is removable by the Stratasys WaterJet System, which removes support material from high-quality 3D models in a self-contained cleaning unit and a small separate pressure pump unit.

KEY FEATURES

Dual spray and jet nozzles for accurate water flow.

Small footprint that is favourable for offices.

Ideal for both delicate and robust model structures.

SUP 707 is removable by the Hands-Free cleaning method of soak-and-rinse process.
